CHS40E-6

Perfect for busy environments, the unit provides convenient access and consistent performance. The CHS40E-6 offers a well-proportioned layout of 44″W x 87″D x 63″H, ideal for professional display needs. Built to endure the demands of daily commercial use, this model ensures both form and function.

Designed for use in rows of 40E series service cases, the Howard McCray CHS40E-6 full service heated display case has removable end panels. It features five individually controlled wells, each with a separate drain and a coated heat lamp. Designed for wet or dry operation, the wells are versatile and maintain warm serving temperatures for already-cooked food. This unit includes extruded doors that slide open on tracks and a vented front that prevents moisture buildup on the single-pane glass front. Made durable for high-volume use, this unit is constructed of stainless steel with a white exterior.

Product Details

• Designed for lineup with 40E series service cases
• Stainless steel top and interior for durability
• White interior finish
• Tempered front safety glass
• 5 individually controlled wells designed for dry or wet operation
• Separate drain and heat lamp for each well
• Vented front minimizes moisture buildup on the front
• Double-pane, removable, rear sliding doors
• 1-in. bumper

Dimensions & Utilities

• 100.5 in. W x 39 in. D x 53 in. H
• 8.7/34.6 A
• 120, 208 V/60 Hz/1 ph

Shipping Dimensions & Utilities

Hot Food Case, 76-1/2″W, (4) individual thermostatically controlled wells, wet or dry operation, single pane glass front, rear sliding removable double pane doors, stainless steel top, white exterior & stainless-steel interior
